Atmel AT24C04 AT24C08 AT24C16 Card

Product Details:

Description

Overview
The AT24C04/08/16 series is a family of serial EEPROM memory solutions offering capacities of 4096 bits (AT24C04), 8192 bits (AT24C08), or 16384 bits (AT24C16). The memory is organized into 512, 1024, or 2048 words of 8 bits each, providing flexible storage options for various applications. Designed for low-power and low-voltage operations, these EEPROMs are ideal for use in space-constrained and power-sensitive environments.

These EEPROMs are commonly used in various industrial and commercial applications, including electricity meter cards, water meter cards, gas meter cards, hotel key cards, and membership cards. Available in space-saving packages such as 8-lead PDIP, 8-lead JEDEC SOIC, and 8-lead MAP, they are well-suited for applications where size and power efficiency are crucial.


Key Features of the AT24C04/08/16 Serial EEPROM

  • Material: PVC, PET, PET-G, PC
  • Size: CR80 standard (86*54mm), custom sizes available
  • Chip: AT24C04/08/16
  • Lifetime: >1,000,000 write cycles, >25 years
  • Capacity:
    • AT24C04: 4096 bits
    • AT24C08: 8192 bits
    • AT24C16: 16384 bits
  • Memory Organization: Organized into 512 (AT24C04), 1024 (AT24C08), or 2048 (AT24C16) words of 8 bits each
  • Low Power: Optimized for low-power and low-voltage operations, making it ideal for battery-operated applications.
  • Communication: I2C interface for easy integration with microcontrollers and processors.
  • Package Options: Available in 8-lead PDIP, 8-lead JEDEC SOIC, and 8-lead MAP, this product provides flexible packaging options for various designs.

Why Choose the AT24C04/08/16 Serial EEPROM?

  • Low Power Consumption: The AT24C04/08/16 is designed for low-power operations, making it suitable for battery-powered applications.
  • Compact and Versatile: Available in small package sizes, it’s ideal for space-constrained applications.
  • High Endurance: The chip is designed for long-term reliability with a lifespan of >1,000,000 write cycles.
  • Flexible Memory Capacities: Choose between 4096 bits, 8192 bits, or 16384 bits of storage, depending on your application needs.
  • Broad Application Range: Commonly used in metering cards, membership cards, and access control systems.

Application Areas
The AT24C04/08/16 series is perfect for applications such as:

  • Electricity Meter Cards
  • Water Meter Cards
  • Gas Meter Cards
  • Membership Cards
  • Hotel Key Cards
  • Fuel Cards
  • Access Control Cards
  • Public Transportation CardsAtmel AT24C04 AT24C08 AT24C16 Card use

Professional Product Support
At DCCO, we offer top-quality smart card solutions. We are here to assist you whether you require custom designs or bulk orders.

  • Contact Us: If you have any questions or need assistance, don’t hesitate to let us know. We also provide exclusive NFC tags and other smart card solutions to meet your needs.
  • Customization: We accept custom orders tailored to your specific requirements.

Technical Specifications

Attribute Details
Material PVC, PET, PET-G, PC
Size CR80 standard (86*54mm), custom sizes available
Chip AT24C04/08/16
Lifetime >1,000,000 write cycles, >25 years
Capacity AT24C04: 4096 bits, AT24C08: 8192 bits, AT24C16: 16384 bits
Memory 512 words (AT24C04), 1024 words (AT24C08), 2048 words (AT24C16)
Interface I2C
Low Power Yes
Package Options 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead MAP

Frequently Asked Questions (FAQs)

Q: What applications can use the AT24C04/08/16 EEPROM?
A: The AT24C04/08/16 is widely used in electricity meter cards, water meter cards, gas meter cards, hotel key cards, membership cards, and other applications requiring low-power, compact memory.

Q: Can I customize the AT24C04/08/16 EEPROM for my project?
A: We offer custom memory configurations and different package options to meet your specific needs.

Q: What is the write cycle endurance of this EEPROM?
A: The AT24C04/08/16 offers an impressive >1,000,000 write cycles, ensuring long-lasting reliability.
